VersaOBJECT MO-Series Direct-to-Object Printer
Take your business to new heights with the VersaOBJECT MO Series Flatbed Printer. Incredibly advanced yet easy to use, this state-of-the-art UV flatbed enables you to grow your business and enter lucrative new markets by providing:
- Unsurpassed Image Quality: Reproduce complex graphics – even the most detailed designs and text – with amazing color vibrancy and accuracy.
- Outstanding Productivity: Maximize your capabilities with a state-of-the-art UV device uniquely designed to streamline workflow, maximize output, and increase profits.
- Greater Versatility: Print on a vast array of substrates and three-dimensional objects up to 8” thick, including cylindrical items with the optional Rotary Rack attachment.
- Intuitive Interface: A 7-inch color touchscreen control and feature-filled, user-friendly VersaWorks 6 software make operation simple.
| Model | MO-240 | MO-180 | ||||||
| Printing Method | Piezo ink-jet method | |||||||
| Attachable objects to be printed on |
Width | Max. 25.1 in. (640 mm) | Max. 19.2 in. (488 mm) | |||||
| Length | Max. 19.2 in. (488 mm) | Max. 13.1 in. (335 mm) | ||||||
| Thickness | Max. 8 in. (204 mm) | Max. 8 in. (204 mm) | ||||||
| Weight | Max. 17.6 lb. (8 kg) (When using a vacuum table: max. 8.8 lb. [4 kg]) | |||||||
| Printing width/printing length (width x length) | Max. 24 in. × 18 in. (610 mm × 458 mm) | Max. 18 in. × 12 in. (458 mm × 305 mm) | ||||||
| Ink | Type | ECO-UV (EUV5P) 750 ml pouch, UV-Ink (EUV-A) 750 ml pouch, UV-Ink (V-BOND) 750 ml pouch | ||||||
| Colors | ECO-UV (EUC5P) Eight colors (Cyan, Magenta, Yellow, Black, Gloss, White, Orange, Red) Seven colors (Cyan, Magenta, Yellow, Black, White, Orange, Red) and Primer Seven colors (Cyan, Magenta, Yellow, Black, Gloss, White, Red) and Primer Seven colors (Cyan, Magenta, Yellow, Black, White x2, Orange and Red） Six colors (Cyan, Magenta, Yellow, Black, Gloss, White x2) and Primer Six colors (Cyan, Magenta, Yellow, Black, Gloss x2, and White x2） Four colors (Cyan, Magenta, Yellow, Black) x2 UV-Ink (EUV-A) Six colors (Cyan, Magenta, Yellow, Black, Gloss x2, and White x2） UV-Ink (V-BOND) Six colors (Cyan, Magenta, Yellow, Black, Gloss, and White) |
|||||||
| Ink-curing unit | Built-in UV-LED lamp | |||||||
| Printing resolution (dots per inch) | Max. 1,200 dpi | |||||||
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | |||||||
| Power-saving function | Automatic sleep feature | |||||||
| Power requirements | 100–240 Va.c. 50/60 Hz 3.5A | |||||||
| Power consumption | During operation | Approx. 290 W | ||||||
| Sleep mode | Approx. 70 W | |||||||
| Acoustic noise level | During operation | 60 dB (A) or less | ||||||
| During standby | 49 dB (A) or less | |||||||
| Dimensions (width x depth x height) | 63.1 in. × 49.9 in. × 30.0 in. (1,601 mm × 1,267 mm × 760 mm) | 57.1 in. × 37.9 in. × 30.0 in. (1,449 mm × 961 mm × 760 mm) | ||||||
| Weight | 465.18 lb. (211 kg) | 383.61 lb. (174 kg) | ||||||
| Environment | During operation(*1) | Temperature: 68 to 89.6 °F (20 to 32 °C), Humidity: 35 to 80 %RH (no condensation) | ||||||
| Not operating | Temperature: 41 to 104 °F (5 to 40 °C), Humidity: 20 to 80 %RH (no condensation) | |||||||
| Included items | Power cord, cleaning liquid, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect) etc. | |||||||
*1 Operating environment (Use the machine in an operating environment within these ranges.)
